| Cisco Compatible | QSFP-100G-SR4-S | Nome do vendedor | FS |
| Fator de forma | QSFP28 | Taxa máxima de dados | 103.125Gbps (4x 25.78Gbps) |
| Comprimento de onda | 850nm | Max Cable Distance | 70m@OM3/100m@OM4 |
| Connector | MTP/MPO-12 | Media | MMF |
| Tipo de transmissor | VCSEL 850nm | Tipo de receptor | ALFINETE |
| TX Power | -8.4~2.4dBm | Receiver Sensitivity | <-10.3dBm |
| Powerbudget | 1.9dB | Receiver Overload | 2.4dBm |
| Typical Power Consumption | ≤1.8W | Extinction Ratio | ＞3dB |
| DDM/DOM | Suportado | Faixa de temperatura comercial | 0 a 70°C (32 a 158°F) |
| CDR (Relógio e Recuperação de Dados) | Texas & RX CDR integrado | FEC Function | Suportado |
| Protocolos | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI | garantia | 5 Anos |
Cisco QSFP-100G-SR4-S Compatible 100GBASE-SR4 QSFP28 850nm 100m DOM MTP/MPO-12 MMF Optical Transceiver Module
$99.00
Cisco QSFP-100G-SR4-S Compatible 100GBASE-SR4 QSFP28 Optical Transceiver Module (MMF, 850nm, 100m, MTP/MPO, DOM)
The Cisco QSFP-100G-SR4-S Compatible QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 100m over OM4 multimode fiber (MMF) using a wavelength of 850nm via a MTP/MPO-12 connector. This transceiver is compliant with IEEE 802.3bm 100GBASE-SR4 and CAUI-4 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core and distribution layer applications.
