[ma-sfp-1gb-lx10 datasheet]
1. Introdução
1.1 Product Overview
1.2 Key Features
2. Specifications
2.1 Electrical Specifications
2.2 Optical Specifications
2.3 Mechanical Specifications
3. Key Benefits
3.1 High-Speed Performance
3.2 Long Distance Connectivity
3.3 Compatible with Various Devices
4. Application Scenarios
4.1 Enterprise Networks
4.2 Data Centers
4.3 Telecommunication Networks
5. Ordering Information
1. Introdução
1.1 Product Overview
The MA-SFP-1GB-LX10 is a highly reliable and high-performance Small Form-Factor Pluggable (SFP) transceiver module designed for Gigabit Ethernet applications. It is compatible with various networking devices and provides long-distance connectivity.
1.2 Key Features
– Supports 1 Gigabit Ethernet data rate
– Operates over single-mode fiber
– Provides a link distance of up to 10 kilometers
– Compliant with IEEE 802.3z standard
– Hot-pluggable SFP footprint
– Digital diagnostics monitoring (DDM) function
2. Specifications
2.1 Electrical Specifications
– Interface: LC duplex connector
– Data Rate: 1.25 Gbps
– Operating Voltage: 3.3V
– Maximum Power Consumption: 1C
– Power Supply: Single +3.3V power supply
2.2 Optical Specifications
– Media: Single-mode fiber
– Comprimento de onda: 1310nm
– Link Distance: Up to 10km
– Fiber Type: 9/125μm
2.3 Mechanical Specifications
– Fator de forma: SFP
– Dimensions: 8.5mm x 13.4mm x 56.5mm
– Weight: 18g
– Operating Temperature: 0°C to 70°C
– Storage Temperature: -40°C to 85°C
3. Key Benefits
3.1 High-Speed Performance
The MA-SFP-1GB-LX10 supports a data rate of 1 Gigabit per second, providing high-speed performance for demanding network applications. It ensures fast and reliable data transmission.
3.2 Long Distance Connectivity
This transceiver module supports a link distance of up to 10 kilometers, allowing for long-distance connectivity between network devices. It is suitable for use in scenarios where network devices are located far apart.
3.3 Compatible with Various Devices
The MA-SFP-1GB-LX10 is compatible with a wide range of networking devices, including switches, routers, and media converters. It can be easily integrated into existing network infrastructures, providing flexibility and scalability.
4. Application Scenarios
4.1 Enterprise Networks
The MA-SFP-1GB-LX10 is ideal for use in enterprise networks, connecting different departments and offices within a company. It ensures reliable and high-speed data transmission, supporting various applications such as email, file sharing, and video conferencing.
4.2 Data Centers
In data center environments, where large amounts of data need to be processed and transmitted, the MA-SFP-1GB-LX10 provides an efficient and reliable solution. It enables high-speed connectivity between servers, switches, and storage devices.
4.3 Telecommunication Networks
Telecommunication networks require long-distance connectivity for delivering voice and data services. The MA-SFP-1GB-LX10 is capable of connecting different network elements, such as transmission equipment and access devices, over long distances.
5. Ordering Information
– Product Name: MA-SFP-1GB-LX10
– Número da peça: XXXX-XXXXX
– Quantity: Specify the required quantity
– Lead Time: Specify the expected lead time for delivery
In conclusion, the MA-SFP-1GB-LX10 is a reliable and high-performance SFP transceiver module designed for Gigabit Ethernet applications. Its key features, such as high-speed performance, long distance connectivity, and compatibility with various devices, make it a versatile solution for enterprise networks, data centers, and telecommunication networks.
